Delivery Date:
12/07/2021
Department Name:
Harwinton Fire Department
Department City / State:
Harwinton, CT

Sutphen Corporation – HS #6951

Dealer – MES – Shipman’s Fire

WHEELBASE: 197”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 31’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Half Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12 500HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 3” Deck Gun
  • Crosslay: (2) 2 ½” Valve-Piping 2 ½” Swivels
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Akron 125 GPM 3126 By-Pass w/ Flush to a Discharge Line for One Foam Tank

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 60 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package: 35’ 3 Section & 14’ Roof & 10’ Folding
  • Body: PS-07 – RED 50/47 Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless-Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Hannay Electric Ladder Rack, 150’ (1)
  • Generator: Smart Power 8KW TM HYD
  • Zico Electric Ladder Rack
  • Whelen 72” Freedom Lightbar with (2) PFH1 Brow Light
  • Whelen PFH2 Recessed Scene Light
  • Whelen TAL65 36” Traffic Advisor
  • Go Light with Custom Riser
