Delivery Date:
12/14/2021
Department Name:
Marion Township Fire Department
Department City / State:
Marion Township, Ohio

Sutphen Corporation – HS #6945

Dealer – Herb Fire Equipment

WHEELBASE: 200”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 32’ – 8”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Half Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 35,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX XS-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right, (1) 2 ½” Pipe Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 1 ½” Speedlay with Liftout Tray
  • Crosslay: (1) 2 ½”
  • 2,000-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foam System: Hale Smartfoam 2.1A

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 130 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’2 Section & PRL-14 14’ Roof & 10’ Folding
  • Body: Stainless Dry-Side Tanker

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC Inview Trueview, Single Camera
  • Newton 10 x 10 Electric, w/ Swivel Dump
  • FireTech 3-Piece Brow Light
  • Whelen 72” Freedom Lightbar
  • Whelen L31 Beacon
  • FRC Spectra 900 12V Scene Lights
