Department Name:
Athens-Clarke County
Department City / State:
Athens-Clarke County, GA

Sutphen Corporation – HS #6529-30

Dealer – Williams Fire Apparatus

WHEELBASE: 196”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 32’ – 5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QFLO-1250 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 2 ½” Left Rear, (1) 3” Deck Gun
  • Crosslay: (2) 1 ½”with w/Swivel, (1) 2 ½” w/ Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 222 cu. ft. Base Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: G2-Alum 40/51 lad chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Back-up Camera
  • 8 Bottle Compartments
  • Firetech HiViz LED Brow Light
  • Whelen 600 LED Scene Lights
  • Whelen Freedom IV LED Lightbar
  • Whelen 600 Rota-beam LED Warning Lights
  • Firetech Guardian Elite Lights
  • Whelen PFH2 12V Telescopic Lights
  • Guardian Elite Scene Light
