Delivery Date:
05/27/2020
Department Name:
Duncan Fire Department
Department City / State:
Duncan, OK

WHEELBASE: 215”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 34’ – 8”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Niehoff 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 1 ½” Front Bumper, (1) Deck Gun
  • Speedlay: (2) 2” w/ 1 ½” Swivel
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Akron w/ flush Foam System

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 246 cu. ft. Base Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: G9-Alum 40/51 lad thru chute

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Safety Vision Camera System
  • Honda EU2200i w/ Akron LED Light Generator
  • 4 Bottle Compartments
  • FRC Spectra Brow Light
  • Whelen Freedom IV 72” LED Lightbar
  • FRC Spectra Telescopic Lights
  • Firetech Rear Work Lights
  • Whelen 600 LED Red Lights
