Delivery Date:
04/14/2019
Department Name:
Madisonville IFC
Department City / State:
Madison Township, PA

WHEEL BASE: 254”

TRAVEL HEIGHT: 9’ – 11 ½”

TRAVEL LENGTH: 34’ – 5 ½”

CHASSIS:             Freightliner 114 SD 4 Door

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension: 20,000 lbs
  • Rear Axle and Suspension: 30,000 lbs
  • Engine: Cummins, L9, 450 HP
  • Transmission: 3000 EVS

PUMP:                 Hale

  • QMAX-1500, Single State Pump
  • Discharge: (2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 3” Deck Gun, (1) 1 ½” Front Bumper
  • Speedlays: (2) 2” with 1 ½” Swivel
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 159 cu. ft. Total Compartment Space
  • Ladder Chute
  • Alco-Lite Ladders (PEL-24 24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)

OPTIONAL EQUIPMENT:

  • 14” Extended Chrome Steel Bumper
  • Whelen 62” Justice Lightbar
  • Whelen M6 Warning Light
  • Whelen M6 Scene Lights
  • Whelen L31 Beacons
  • Fire Tech Work Lights
  • Zico Ladder Rack
  • Light FR Spectra, LED, Tele, 15K Lumens, 12V
