Delivery Date:
04/12/2019
Department Name:
City of Griffin Fire Department
Department City / State:
City of Griffin, GA

WHEEL BASE: 215”

TRAVEL HEIGHT: 9 – 10”

TRAVEL LENGTH: 33’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: 2 ½” Crosslay in Dunnage Area
  • Speedlays: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 246 cu. ft. Total Compartment Space
  • Alco-Lite Ladders (PEL-24 24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)
  • Ladder Chute with Backboard Storage

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel
  • Honda 2200 I Portable Generator
  • FRC Spectra Brow Light
  • FRC, Inview Trueview, Camera System
  • Whelen Freedom LED Lightbar
  • Whelen M9 Scene Lights
  • Whelen LED TAL 65 36” Traffic Advisor
  • Federal Q2B Siren
  • Akron 3423 Apollo Monitor
