Delivery Date:
02/02/2021
Department Name:
Bethel-Tate Fire Department, Ohio
Department City / State:
Bethel, Ohio

Sutphen Corporation – HS #6741

Dealer – Heritage Fire Equipment

WHEELBASE: 198”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33’ – 4 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 48,000 lbs
  • Engine: Cummins X 12, 455 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP:                 Waterous

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (3) 2” w/ 1 ½” Swivels
  • 2,500-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 125 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding)
  • Body: SWT-04A STS Wet Side Tanker Tandem

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Newton 10 x 10 Electric, with Swivel Dump
  • 2,100 Gallon Portable Tank
  • Camera System: FRC, Inview Trueview, Single Camera
  • Whelen Freedom IV 72” LED Light Bar
  • Whelen L31 Beacons
  • Whelen 900 LED Scene Lights
  • FireTech 3-Piece 72” LED Brow Light
