Delivery Date:
04/23/2020
Department City / State:
Bucyrus, OH

WHEELBASE: 197”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 33’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • XS QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Left, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 1 ½” w/ Lift-out Tray
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 60 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 14’ Roof & 10’ Folding)
  • Fully Enclosed Ladder Chute
  • Body: S8-56/53 Lad Thru Water Tank

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • 2 Bottle Compartments
  • Firetech 72” LED Brow Light
  • Firetech Guardian LED Scene Lights
  • Whelen Freedom LED Lightbar
  • Whelen 900 LED Red Lights
