Delivery Date:
02/15/2019
Department Name:
Whiting Fire Company
Department City / State:
Whiting, NJ

Sutphen Corporation – HS #6224

Dealer – Blaze Emergency Equipment

WHEEL BASE: 232 ½”

TRAVEL HEIGHT: 9’ – 11 ¾”

TRAVEL LENGTH: 35’ – 10 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof

  • Four-Door, Seven-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM
  • Discharges: (1) 4” Left, (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • 1,000-Gallon Water Tank
  • 50-Gallon Foam Tank
  • Hale Foamlogix 5.0

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Doors
  • 301 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24 (24’ 2-Section & PRL-14; 14’ Roof & 10’ Folding)

OPTIONAL EQUIPMENT:

  • 10KW Smart Power Generator
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Hannay Electric Cord Reel, 200’ (2)
  • FRC Spectra Tripod Lights
  • FRC Spectra Brow
  • Federal Sig 73” Lightbar
  • Wilburt NS3.0-920SPC Light
  • Voyager 3, Split Screen, Camera System
