Delivery Date:
06/18/2020
Department Name:
Wethersfield Fire Department
Department City / State:
Wethersfield, CT

WHEELBASE: 199”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 32’ – 6”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Seven-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Front Left, (1) 2 ½” Right Rear, (1) 3” Deck Gun
  • Crosslay: (1) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 70 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Enclosed ladder chute
  • Body: PA – 02 RES 43/53

ADDITIONAL EQUIPMENT:

  • 12” Formed Steel Channel
  • Federal Q2B Siren, Grille Mount
  • 4 Bottle Compartments
  • Safety Vision Camera System
  • SmartPower 10KW Generator
  • Whelen PFH2 12V Brow Light
  • Whelen Freedom IV LED Lightbar
  • Whelen 900 LED Scene Lights
  • Whelen MCF LED Beacons
  • Rigid D2 LED Flood Lights
