Delivery Date:
02/17/2022
Department Name:
Indian River County Fire Rescue
Department City / State:
Vero Beach, FL

Sutphen Corporation – HS #6978-79

Dealer – South Florida Emergency Vehicles

WHEELBASE: 196”

TRAVEL HEIGHT: 10’ – 0”

TRAVEL LENGTH: 32’ – 3”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000R w/ Retarder

PUMP:                  Waterous

  • S101 – 1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” Crosslay & Speedlay, (2) 2” Crosslays w/ Swivels & Poly Lift-Out Trays
  • 750-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foam System: Elkhart w/ Flush

BODY:                   Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors, Satin Finish
  • Over 290 cu ft. Total Compartment Space
  • Alco-Lite Pel-24 Ladders: (1) 24’ 2-section, (1) PRL-14 14’ Roof, (1) 10’ Folding
  • Body: G9, Alum 40/51 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Whelen Freedom LED Lightbar
  • FRC Spectra Brow Light
  • Whelen 900 Scene Light
  • FRC Spectra LED Tele Lights
