Delivery Date:
06/25/2020
Department Name:
Town of North Haven
Department City / State:
North Haven, CT

WHEELBASE: 219”

TRAVEL HEIGHT: 9’ – 11 ½”

TRAVEL LENGTH: 33’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 24,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel, (1) 2 ½” w/ 2 ½” Swivel
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Akron Foam System

BODY:                  Sutphen

  • ROM Roll-Up & Slam Doors Compartment Doors
  • 90 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: PA – 17, 43/53

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel Bumper
  • Federal Q2B Siren, Grille Mount
  • 7 Bottle Compartments
  • Camera System, For VMUX, Rear/Left/Right
  • SmartPower 6KW Generator
  • Whelen PFH2 Brow Light
  • Whelen Freedom 72” Lightbar
  • Whelen M9 Scene Lights
  • Whelen M9 Warning Lights
