Delivery Date:
06/17/2020
Department Name:
Fire District #28
Department City / State:
Gibsonville, NC

WHEELBASE: 266”

TRAVEL HEIGHT: 10’ – 7”

TRAVEL LENGTH: 37’ – 2”

CHASSIS:             Freightliner SD-114

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: For Commercial Chassis
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Right, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 2” w/ 1 ½” Swivel
  • 1,250-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 30 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: C3 – 43/53

ADDITIONAL EQUIPMENT:

  • 20” Extended Bumper
  • Federal Q2B Siren, Grille Mount
  • 9 Bottle Compartments
  • FRC, Inview Trueview Camera System
  • PFP2 Brow Light
  • Whelen Freedom 60” Lightbar
  • Whelen 900 Scene Lights
  • Whelen 900 Warning Lights
  • Whelen M6 Warning Lights
  • Whelen M6V2 Cornering Lights
  • PFH2 Telelights
