Delivery Date:
11/20/2019
Department Name:
Tafton Fire Company
Department City / State:
Tafton, PA

Sutphen Corporation – HS #6466

Dealer – Signal 1 Fire Equipment

WHEEL BASE: 205”

TRAVEL HEIGHT: 11’

TRAVEL LENGTH: 33’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-XS-1750 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Valve 3” Pipe to Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 1 ½” Speedlays with Poly Liftout Tray & (1) 2 ½” Speedlay
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 270 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body: PA-01 Res 30/53 Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Hannay Electric Cord Reel, 200’ (1)
  • FRC, Inview 360, Camera System
  • 10KW Smart Power Generator
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Pike Pole Storage Tubes (3)
  • Whelen 62” Justice Lightbar
  • FRC Spectra 12V Brow Light
  • FRC Spectra 12V Brow Light
  • Command Light CL602A-FS 1000W LED Light Tower
