Delivery Date:
02/15/2019
Department Name:
Swoope Volunteer Fire Department
Department City / State:
Swoope Volunteer Fire Department

Sutphen Corporation – HS #6257

Dealer – Ron Garber

WHEEL BASE: 173”

TRAVEL HEIGHT: 9’ – 9”

TRAVEL LENGTH: 31’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Pipe to Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½” & (2) 2” Speedlays with 1 ½” Swivel & Poly Lift-Out Tray
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Akron Foam Supply System

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Doors
  • Over 242 cu. ft. Total Compartment Space
  • Duo-Safety (900A 24’ 2-Section & 775A 14’ Roof & Folding)

OPTIONAL EQUIPMENT:

  • 10KW Smart Power Generator
  • Firetech 12V LED Scene Lights
  • FR Spectra, LED, Surface Mint, 20K Lumens
  • Hannay Electric Cord Reel
  • Safety Vision SV-CLCD0-70 Camera System
  • David Clark Intercom System
  • 24” Bumper
  • Federal Q2B Siren
