Delivery Date:
04/30/2020
Department Name:
Rural Ridge Fire Department
Department City / State:
Rural Ridge, PA

Sutphen Corporation – HS #6537

Dealer – FAST of the Allegheny Mountains

WHEELBASE: 179”

TRAVEL HEIGHT: 10’ – 10”

TRAVEL LENGTH: 30’ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Cab w/ 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 13” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Right, (1) 3” Deck Gun
  • Crosslay: (2) 1 ½” w/ Swivel, (1) 2 ½” w/ Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 35’ 3-Section & (2) 14’ Roof & 10’ Folding)
  • Body: G9-Alum 40/51, Lad thru Tank

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel Bumper
  • Federal Q2B Siren, Grille Mount
  • 3 Bottle Compartments
  • FRC Spectra Brow Light
  • FRC Spectra 260 Scene Lights
  • Whelen Freedom IV LED Lightbar
  • Whelen 900 warning Lights
  • FRC Spectra Telescopic Lights
  • Whelen 600 LED Red Lights
  • HiViz Guardian Elite LED Scene Lights
