Delivery Date:
04/21/2020
Department Name:
Lawsonville Volunteer Fire Rescue
Department City / State:
Danbury, NC

Sutphen Corporation – HS #6525

Dealer – Stevens Fire Equipment, Inc.

WHEELBASE: 185”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 31’ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front Right, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 1 ½” w/ Swivel, (1) 2 ½” w/ Swivel
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • 222 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 14’ Roof & 10’ Folding)
  • Fully Enclosed Ladder Chute
  • Body: G2-Alum 40/51, Lad Chute

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper
  • Federal Q2B Siren, Grille Mount
  • Safety Vision Camera System
  • Smart Power Generator
  • 4 Bottle Compartments
  • Whelen PFP2 LED Brow Light
  • Firetech Guardian Elite Scene Lights
  • Whelen Justice LED Lightbar
  • Whelen Pioneer Recessed PFH2 Lights
  • Whelen PFP2 12V Telescopic Lights
  • Whelen 600 LED Red Lights
  • Whelen Ion Red Lights
