Sutphen Corporation – HS #6964
Dealer – South Florida Emergency Vehicles
WHEELBASE: 188”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 32’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 15” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX – 1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper
- Crosslays: (2) 2” Crosslays w/ 1 ½” Swivel
- 1000-Gallon Water Tank
- 20-Gallon Foam Tank
- Foam System: Foampro 2002, 5.0 GPM
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors, Painted
- Over 246 cu ft. Total Compartment Space
- Alco-Lite Pel-24 Ladders: (1) 24’ 2-section & (1) PRL-14 14’ Roof & (1) 10’ Folding
- Body: G9 – Alum 40/51 Ladders Through Tank
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Whelen Freedom LED Lightbar
- FRC Spectra Brow Light
- FRC Spectra Tele Light
- Whelen M9 Scene Light
- Camera System: Brigade 360
- Whelen L31 Red LED Beacons
