More Recent Deliveries

Delivery Date:
11/16/2018
Department Name:
New Kent Fire Rescue
Department City / State:
New Kent, VA



Sutphen Corporation

WHEEL BASE: 167”

TRAVEL HEIGHT: 10’-1”

TRAVEL LENGTH: 30’-11”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 13” Single Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Left of Main Hosebed, (1) 2 ½ Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Monitor: TFT, XFIH-DA Hurricane Deck Gun, 1250 GPM Manual
  • Crosslays: (2) 2” with 1 ½” Swivel
  • 20-Gallon Foam Tank
  • FoamPro 2002 System
  • 750-Gallon Water Tank

Body:                   Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • 9 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24 (24’ 2-section and PRL-14 14’ Roof and 10’ Folding)

OPTIONAL EQUIPMENT:

  • 24” Bumper Extension
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Federal Q2B Siren
  • Pike Pole Storage (3)
  • Hannay Booster Reel w/ 150’ (1)
  • Whelen Freedom IV 72” LED Light Bar
