Delivery Date:
11/16/2018
Department Name:
Belington Volunteer Fire Department
Department City / State:
Belington, WV



Sutphen Corporation

WHEEL BASE: 215”

TRAVEL HEIGHT: 9’-8”

TRAVEL LENGTH: 33’-9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L9, 450 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Left of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Monitor: Akron 3423 Apollo
  • Speedlays: Two 2” with 1 ½” Swivel
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Ladder Chute with Pike Pole Storage
  • 3 cu. ft. of Total Compartment Space
  • Amdor Roll-Up Compartment Doors
  • Duo-Safety Ladder Package (35’ 3-section & PRL-14 14’ Roof & 10’ Folding)

OPTIONAL EQUIPMENT:

  • 24” Bumper Extension, 2” Raised Lid
  • Camera System, Safety Vision, SV-CLCD0-70
  • Federal Q2B Siren
  • Whelen Traffic Advisor
  • Whelen Freedom IV 72” LED Lightbar
  • FRC Spectra 12V Brow Lights (2)
  • Whelen 600 LED Super LED Warning Lights
