Delivery Date:
12/14/2021
Department Name:
Little Falls Fire Department
Department City / State:
Little Falls, NY

Sutphen Corporation – HS #6936

Dealer – Vander Molen Fire Apparatus Sales and Service

WHEELBASE: 179”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 30’ – 4”

CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab with a 10 ½” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Domex Double Frame Rails (110K PSI)
  • Front Axle and Suspension 21,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12 500HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS 4500

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Front Left, (1) 2” Front Right, (1) 2 ½” Front Bumper
  • Crosslays: (1) 2 ½”, 2 ½” Swivel, (2) 2” with 1 ½” Swivel Double Stacked
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll Up Compartment Doors
  • Over 200 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package: 900A 24’ 2-section & 775A 14’ Roof & 10’ Folding
  • Body: PA-12 Res 43/53, Ladder Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Steel Channel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Single Camera
  • (2) Triple Air Bottle Compartments
  • Whelen PFH2 Brow Light
  • Whelen M9 Scene Light
  • Whelen PFH2 Tele Lights
  • Whelen 72” Freedom LED Lightbar
