Delivery Date:
05/26/2020
Department Name:
Kirksville Fire Department
Department City / State:
Kirksville, MO

Sutphen Corporation – HS #6539

WHEELBASE: 196”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 32’ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison, EVS3000

PUMP:                 Hale

  • XS QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½”
  • Speedlay: (2) 2” w/ Swivel and Poly Lift-out Tray
  • 1,000-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Hale Smart Foam 2.1A Foam System

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • 246 cu. ft. Base Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body: G9 – Alum 40/51 Lad Thru Tank

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • 3 Bottle Compartments
  • FRC Inview Trueview Camera System
  • Firetech HiViz 3-piece Brow Light
  • Whelen Freedom IV 72” LED Lightbar
  • Guardian Elite Scene Lights
  • Whelen L31 LED Red Lights
  • Whelen M6 LED Warning Lights
  • Low Profile Scene Light
