Delivery Date:
07/17/2019
Department Name:
Jeffersonville Fire Department
Department City / State:
Jeffersonville, NY

Sutphen Corporation – HS #6375

WHEEL BASE: 209”

TRAVEL HEIGHT: 10’ – 11”

TRAVEL LENGTH: 34’ – 2”

CHASSIS:  Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof

  • Four-Door, Six-Person Cab
  • 13” Double Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Niehoff, 430 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP:                 Waterous

  • CSU-1750 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Pipe to Right Rear, (2) 2 ½” Left Rear, (1) 2 ½” Front Bumper Discharge, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslyas w/ 1 ½” Swivel
  • 1,500-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 139 cu. ft. Total Compartment Space
  • Duo Safety (1200A 28’ 2-Section & 775A 14’ Roof & 10’ Folding)

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper
  • Voyager 3 Camera System
  • Federal Q2B Siren, Front Bumper Mount
  • SCBA Bottle Storage (6)
  • Hannay Electric Cord Reel, 150’ (1)
  • 10KW Harrison Generator
  • Whelen 72” Freedom Lightbar with Opticom Integrated
  • Whelen 47” Traffic Advisor
  • Whelen PFH1 Scene Lights (6)
