Delivery Date:
05/29/2020
Department Name:
Jackson Township Fire Department
Department City / State:
Grove City, OH

WHEELBASE: 219”

TRAVEL HEIGHT: 10’ – 5”

TRAVEL LENGTH: 34’ – 11”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 15” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: C. E. Niehoff, 415 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Front Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 1 ½” w/ Poly Lift-out Tray, (1) 2 ½” w/ Poly Lift-out Tray
  • Crosslay: (1) 2 ½”
  • 980-Gallon Water Tank
  • 20-Gallon Foam Tank
  • FoamPro 2001

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 444 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: Modified PA – 16 RES 56/53

ADDITIONAL EQUIPMENT:

  • 30” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • 4 Bottle Compartments
  • FRC Inview Trueview Camera System
  • FRC Spectra 12V LED Brow Light
  • Whelen Freedom IV LED Lightbar
  • FRC Spectra 15k 12V Scene Lights
  • Whelen 900 LED Red Lights
