Department Name:
Ft. Lauderdale Fire Rescue
Department City / State:
Ft. Lauderdale, FL

WHEELBASE: 200”

TRAVEL HEIGHT: 11’ – 3”

TRAVEL LENGTH: 33’ – 7 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QTWO-1500 GPM, 6” Suction Two Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 3 ½” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 712-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: FoamPro 2002

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • Over 300 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & 14’ Roof & 10’ Folding)
  • Fully Enclosed Ladder Chute
  • Body: PA-19, Lad Thru Tank

ADDITIONAL EQUIPMENT:

  • 30” Formed Steel Channel
  • Federal Q2B Siren, Grille Mount
  • FRC Spectra LED 12V Brow Light
  • Whelen M9V2 Combo LED Scene Lights
  • Whelen Freedom IV LED Lightbar
