Delivery Date:
04/14/2019
Department Name:
Clarksville Fire Company
Department City / State:
West Clarksville, NY

WHEEL BASE: 226”

TRAVEL HEIGHT: 9’ – 4 ½”

TRAVEL LENGTH: 29’ – 8”

CHASSIS:             International HV 607 SBA – 2 Door

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension: 20,000 lbs
  • Rear Axle and Suspension: 30,000 lbs
  • Engine: Cummins, L 9, 280HP
  • Alternator: Delco, 320 AMP
  • Transmission: 3000 EVS with Stalk Shifter

PUMP:                 Hale

  • DSD-1250, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear
  • Crosslays: (2) 2” with 1 ½” Swivel (Single Stack), (1) 2 ½” with 2 ½” Swivel (Double Stack)
  • 2,000-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Over 85 cu. ft. Total Compartment Space
  • Alco-Lite Ladders (24’ 2-Section, 14’ Roof and 10’ Folding)

ADDITIONAL EQUIPMENT:

  • Ziamatic Quic-Lift Electric Ladder Rack
  • Federal Q2B Recessed in Bumper
  • Whelen 60” Freedom Lightbar with PFP2 Brow Light
  • Whelen M6 LED Warning Lights
  • Whelen Micro Freedom Beacons
  • FR Spectra A900-Q70, LED, Surface Mount, 12V (2)
  • Safety Vision SV-CLCD0-70, Camera System
