Delivery Date:
04/09/2020
Department Name:
City of Des Moines Fire Department
Department City / State:
Des Moines, IA

Sutphen Corporation – HS #6635

WHEELBASE: 192”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 30’ – 10 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • 149 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (24’ Extension & 14’ Roof & 10’ Folding)
  • Fully enclosed ladder chute
  • Body: Custom, Lad Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • 7 Bottle Compartments
  • Whelen PFH2 12V Brow Light
  • Whelen Freedom IV Lightbar
  • Whelen PFH2 12V Scene Lights
  • Whelen M6 Series Warning Lights
