Delivery Date:
05/15/2020
Department Name:
Ellwood Fire District
Department City / State:
Ellwood, NY
Truck Type:

Sutphen Corporation – HS #6662

Dealer – Herb Fire

WHEELBASE: 221”

TRAVEL HEIGHT: 8’ – 11 ¾”

TRAVEL LENGTH: 42’ – 11 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Side Body, (1) 1 ½” Front Bumper
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • AMDOR Roll-Up Compartment Doors
  • 192.75 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & REL-35 35’ 3-Section & (2) 10’ Folding & (2) PRL-14 14’ Roof)
  • Enclosed ladder chute
  • Body: SAA-4

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • 7 Bottle Compartments
  • Voyager 2 Camera System
  • Harrison 8KW Generator
  • FRC Spectra LED Brow Light
  • Whelen Freedom 4 Lightbar
  • FRC Spectra 240V LED Scene Lights
  • Whelen FNMINI Lightbars
  • Rigid Diffusion LED Rear Work Lights
