Delivery Date:
03/17/2019
Department Name:
Nashville VFC
Department City / State:
Spring Grove, PA

Sutphen Corporation – HS #6318

Dealer – Lawver Fire Apparatus

WHEEL BASE: 199”

TRAVEL HEIGHT: 10’ – 3”

TRAVEL LENGTH: 35’ – 5 ½”

CHASSIS:             Kenworth T800- 2DR

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins ISX 15, 505 HP
  • Alternator: Delco, 320 AMP

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 2 ½” Left Rear
  • 3,800-Gallon Water Tank
  • Crosslay: (2) 2” with 1 ½” Swivel
  • Newton 10” Kwik Dump

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • Amdor Roll-Up Doors
  • 126 cu. ft. Total Compartment Space

ADDITIONAL EQUIPMENT:

  • FRC, Trueview, Camera System
  • Zico Elec Porta Tank Tack with 3,500-Gallon Porta Tank
  • FRC Spectra Telelight
  • Whelen 60” Freedom Lightbar
  • Whelen 600 LED Warning Lights
  • Whelen 900 LED, Scene Lights
  • Federal Q2B Recessed in Bumper
