Delivery Date:
11/19/2020
Department Name:
Germania Fire Company
Department City / State:
Germania, NJ

Sutphen Corporation – HS #6594

Dealer – Blaze Emergency Equipment

WHEELBASE: 183”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 33’ – 4”

CHASSIS:             Kenworth T800 – 2DR

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins ISX 15, 500 HP
  • Transmission: EVS 4500

PUMP:                 Hale

  • Hale Side Kick DSD, 1250 GPM, PTO
  • Discharges: (3) 2 ½” Left, (1) 4” Left Rear
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 3,500-Gallon Water Tank

BODY:                  Sutphen

  • Amdor Roll-Up Compartment Doors
  • Over 114 Cu. Ft. Compartment Space
  • Body: SET-05C STS Elliptical Tanker Tandem, Integrated

ADDITIONAL EQUIPMENT:

  • Federal Q2B Siren, Front Bumper Mount
  • Camera System: Voyager 3
  • Zico Electric/Hydraulic Rack, Portable Tank Storage
  • Newton 10” Kwik Dump, STS, Left, Right and Rear
  • Federal Signal 60” Navigator Lightbar
  • Federal Signal LP800 Beacons
  • Whelen C6 Warning Lights (6)
  • Whelen 47” Traffic Advisor
