Delivery Date:
08/06/2019
Department Name:
City of Newton Fire Department
Department City / State:
City of Newton, NC

Sutphen Corporation – HS #6342

WHEEL BASE: 240”

TRAVEL HEIGHT: 10’ – 11 ½”

TRAVEL LENGTH: 38’ – 4 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 20” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 1042 cu. ft. Total Compartment Space
  • Alco-Lite Ladders (PEL-24 24’ 2-Section & PRL-16 16’ Roof & 10’ Folding)

ADDITIONAL EQUIPMENT:

  • Fender Oil Dry Hopper
  • 30” Formed Steel Channel Bumper Extension
  • Hannay Electric Cord Reel, 100’ (2)
  • 20KW Onan PTO Generator
  • Whelen Rotobeam Lightbar
  • Whelen 600 Rotobeam Warning Lights
  • Whelen M9 Scene
  • Firetech 3 Piece Brow Light
  • Winch, Warn, 15,000 lbs
  • Federal Q2B Siren, Flush Grille Mount
  • Wilburt VRT-9000-6 OPT-220V
