Delivery Date:
10/14/2020
Department Name:
Community Fire Company
Department City / State:
Landingville, PA
Truck Type:
Sutphen Corporation – HS #6620
Dealer – Signal 1 Fire Equipment
WHEELBASE: 216”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 36’
CHASSIS: Sutphen Monarch Heavy Duty-Custom Chassis, 62” Extended Cab with a 15” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins X 12, 600 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-1500 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Front/Right of Main Hosebed, (1) 3” Front Bumper, (1) 3” Deck Gun
- Crosslays: (1) 2 ½”, 2 ½” Swivel
- Speedlay: (2) 2” Crosslays w/ 1 ½”
- 3,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Hale Smartfoam 2.1A
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- Over 150” cu. ft. Total Compartment Space
- Alco-Lite (PEL-24 24’’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Body: TA-04 – Tanker 56/53 High/Low
ADDITIONAL EQUIPMENT:
- Federal Q2B Siren, Grille Mounted
- 18” Polished Stainless Steel Bumper Extension
- Hannay Electric Cord Reel, 150’ (1)
- Generator: 6KW Smart Power
- Camera: FRC, Inview 360
- Newton Dump Electric Valve with Swivel
- Fire Tech Brow Light with ICC Lights
- Whelen Freedom 72” Lightbar
- Whelen LED, TAL85, 47” Traffic Advisor
