Delivery Date:
05/15/2020
Department Name:
Columbia Fire Department
Department City / State:
Columbia, MO
Truck Type:

Sutphen Corporation – HS #6663

WHEELBASE: 221”

TRAVEL HEIGHT: 10’ – 9 ½”

TRAVEL LENGTH: 39’ – 6”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper
  • Crosslay: (2) 2” w/ 1 ½” Swivel, (1) 2 ½” w/ 2 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • 201.96 cu. ft. Total Compartment Space
  • Duo-Safety Special Ladder Package, Pumper Ladders (24’ 2-Section & (2) 10’ Folding & 10’ Attic & 14’ Roof)
  • Body: Custom, Left High/Right High/Split Depth

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • 5 Bottle Compartments
  • Safety Vision Camera System
  • Smart Power 8KW Generator
  • FRC Spectra Brow Light
  • Whelen Freedom IV Lightbar
  • Whelen M9 Scene Lights
  • Whelen L31 LED Rear Beacon
  • Whelen 600 Amber Light
  • Rigid D2 LED Spotlights
