Delivery Date:
02/21/2020
Department Name:
Grand Blanc Fire department
Department City / State:
Grand Blanc, MI
Truck Type:

WHEELBASE: 221”

TRAVEL HEIGHT: 10’ – ½”

TRAVEL LENGTH: 41’ – ¼”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left, (1) 1 ½” Front Bumper
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • 75 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & REL-35 35’ 3-Section & (2) PRL-16 16’ Roof & (2) 10’ Folding)
  • Body: SAA 4 Left High/ Right Intermed/ Trans

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Back-up Camera
  • Smart Power Generator
  • FRC Spectra LED 12V Brow Light
  • FRC Spectra Max 240V LED Scene Lights
  • Whelen Freedom 4 LED Lightbar
  • Whelen 900 LED Lights
