Delivery Date:
04/14/2019
Department Name:
Des Moines Fire Department
Department City / State:
Des Moines, IA

WHEEL BASE: 241”

TRAVEL HEIGHT: 9’ – 9”

TRAVEL LENGTH: 42′ – 2 ¼”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension: 23,000 lbs.
  • Rear Axle and Suspension: 31,000 lbs.
  • Engine: Cummins X 12, 50 0HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX-2000 GPM Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
  • Monitor: Elkhart 7205 Cobra EXM with SM1500E Nozzle
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Duo-Safety Ladders (115’: 14’C, 16’R, 16’R, 24’ 2-Section, 35’ 3-Section & 10’ F)
  • Over 171 cu. ft. Total Compartment Space
  • Ladder Chute
  • Body Left High / Right Low / Trans Rear

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • Federal Q2B Grille Mount
  • 10KW Onan Generator
  • Whelen Freedom 4 Lightbar
  • Whelen PFH2 12V LED Brow Lights (2)
  • Whelen PCP2AFS 115V Scene Lights
  • Hannay Electric Cord Reel, 150’ (2)
  • Rigid D2 LED Boom Spotlights
