Delivery Date:
08/10/2018
Department Name:
Cahokia Volunteer Fire Department
Department City / State:
Cahokia, Illinois
Truck Type:

Sutphen Corporation – HS #6155

Dealer – Cashion Fire Equipment

WHEEL BASE: 231”

TRAVEL HEIGHT: 10’ – 0 ½”

TRAVEL LENGTH: 41’ – 0 ¼”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

Pump:                  Hale

  • QMAX-2250 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 2 ½” Front Bumper
  • Monitor: TFT Y5-E11A-L30, Typhoon Elec w/ M-ERP-1500 Nozzle
  • Crosslays: (2) 2” Valve-Piping, 1 ½” Swivel
  • 20-Gallon Foam Tank
  • 500-Gallon Water Tank

Body:                   Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • 188 cu. ft. of Total Compartment Space
  • SAA-2 Left High/Right Low/Trans Rear
  • Duo-Safety Custom Ladders (14’ R, 16’R, 16’R, 24’-2 Section, 10’F, 10’ F

OPTIONAL EQUIPMENT:

  • 24” Bumper
  • Single Camera, Pro-Vision, Camera System
  • Federal Q2B Siren
  • Hannay Booster Reel (1)
  • Pike Pole Storage Tube (3)
  • PowerArc VM8506QEL-6P Light Bar
