Delivery Date:
03/21/2022
Department Name:
Cape Floral Fire Department
Department City / State:
Cape Floral, FL
Truck Type:

Sutphen Corporation – HS #7015

Dealer – South Florida Emergency Vehicles

WHEELBASE: 253”

TRAVEL HEIGHT: 10’ – 1 ½”

TRAVEL LENGTH: 45’ – 5 ¾”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Tandem Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 48,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX – 2000 GPM 6” Suction, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
  • Crosslays: (2) 2” Valve-Piping w/ 1 ½” Swivel
  • 400-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Foampro 2002, 5.0 GPM

BODY:                   Sutphen

  • Huckbolted #304 Stainless Steel
  • Amdor Roll-Up, Painted & Aluminum Hinged, Painted
  • Over 267 cu ft. Total Compartment Space
  • Alco-Lite Ladders: (1) 14’, (2) 16’, (1) 24’ 2-section, (1) 35’ 3-section & (1) 10’ Folding
  • Body: SPH-3, Left 56” H / Right 56” H

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Whelen Freedom IV Lightbar
  • FRC Spectra Max 12V LED Brow Light
  • FRC Spectra 120V LED 20K Scene Light
  • Camera System: Brigade 360
  • Intercom System: FRC ACT 3-Station
  • Hannay Reel w/ 150’ 10/3 (1)
