Delivery Date:
12/01/2017
Department Name:
Orlando Fire Department
Department City / State:
Orlando, FL

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ 11” ±2″

TRAVEL LENGTH: 32’-1”

CHASSIS:              Sutphen 62” cab with flat roof

  • Four-Door, Seven-Person Cab
  • Front Suspension: 18,000 lbs.
  • Rear Axle: 24,000
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • 1500 GPM Single Stage
  • Discharge: (2) 2.5” Left, (2) 3” right, 2.5” Left Rear, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing, 3″ Deck Gun
  • 750 Gallon Water Tank
  • 30 Gallon Foam Tank

BODY:                   Sutphen

  • Aluminum
  • 222 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Federal Q2B
  • Magnagrip Adapter
  • Automatic Lube System, Groenveld, single stage
  • Crew Cab Fan
  • Manual Pump Shift Override
  • Pressure control, FRC Pump Boss
  • Backboard stop in right side of hosebed
