Department Name:
Cochranton Volunteer Fire Department
Department City / State:
Cochranton, PA



Sutphen Corporation

WHEEL BASE: 211”

TRAVEL HEIGHT: 9’-10”

TRAVEL LENGTH: 34’-4”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 48,000 lbs
  • Engine: Cummins ISX 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper
  • 30-Gallon Foam Tank
  • Foam System Foam Pro 2001
  • 2,500-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Door
  • 127 cu. ft. Total Compartment Space
  • Alco-Lite Ladders (35’, 3-Section, 18’ RF, 10’ Fold with Two Pike Poles)

OPTIONAL EQUIPMENT:

  • 24” Bumper Extension
  • Voyager 3 Camera System
  • Federal Q2B
  • 10KW Onan Generator
  • Hannay Electric Cord Reel, 200’ (1)
  • Whelen 72” Freedom Lightbar
  • FR Spectra Brow Light
  • Ziamatic Quic-Lift Electric Ladder Rack
