Delivery Date:
03/15/2019
Department Name:
Perry Township Fire Department
Department City / State:
East Liberty, Ohio

Sutphen Corporation – HS #6261

Dealer – Heritage Fire Equipment

WHEEL BASE: 191”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 30’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 35,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
  • 2,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Doors
  • Over 147 cu. ft. Total Compartment Space
  • Alco-Lite (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body TA-01 Tanker 56/53 High/Low – Ladder Chute

ADDITIONAL EQUIPMENT:

  • 6KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • Safety Vision SV-CLCD0-70, Camera System
  • 6” Chrome Bumper Extension
  • Federal Q2B Siren, Flush Grille Mount
  • FR Spectra 900 Scene Lights
  • FR Spectra 20K Brow Light
  • Whelen 72” Freedom IV Lightbar
  • Whelen 600 Series Warning Lights
  • Whelen LED L31 Beacons
