Delivery Date:
02/15/2019
Department Name:
Celoron Hose Company
Department City / State:
Jamestown, NY

WHEEL BASE: 215”

TRAVEL HEIGHT: 10’ – 9 ¼”

TRAVEL LENGTH: 41’ – 9 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab with a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP                   Hale

  • QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side
  • Monitor: (1) TFT Y5-E11A-L Typhoon w/ M-ERP-1500 Nozzle and (1) TFT Y4-M15A Monsoon Manual w/ Nozzles & Streamshaper
  • Crosslays: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslays with 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Over 193 cu. ft. Total Compartment Space
  • Alco-Lite Quint Ladder Compliment (85’: 16’R, 24’ 2-Section, 35’ 3-Section & 10’F)
  • Left High/Right Intermed/Trans

OPTIONAL EQUIPMENT

  • 6” Bumper Extension
  • FRC Inview Trueview, Single Camera, Camera System
  • Federal Q2B
  • 6KW Harrison Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom 4 Lightbar w/ (2) FN Mini Lightbars
  • FRC Spectra 12V LED Brow Light
