Delivery Date:
11/20/2021
Department Name:
Wickliffe Fire Department
Department City / State:
Wickliffe, OH
Truck Type:
Sutphen Corporation – HS #6927
Dealer – Herb Fire Equipment
WHEELBASE: 226”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 34’ – 9”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Hale
- QMAX 1500 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlays: (2) 2” w/ 1 ½” Swivels and Poly Lift-Out Trays
- Crosslay: (1) 2 ½“ W/ 2 ½“ Swivel
- 750 Gallon Water Tank
- 25 Gallon Foam Tank
- Foam System, Akron 95 GPM 3096 Internal Eductor W/ Flush Valve
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor & ROM Roll-up Compartment Doors, Satin Finish
- 294 cu. ft. Total Compartment Space
- Alco-Lite ladder package: PEL-24 24’ 2-sec & PRL-14 14’ Roof & 10’ Folding
- Body: G9 – Aluminum 40/51 Ladders Thru Tank
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Backeye 360 Camera System
- FRC Spectra Brow Light
- Whelen Freedom LED Lightbar
- Whelen M9V Red LEDs Scene
- Whelen LED, TAL65 36” Traffic Advisor
