Delivery Date:
05/30/2025
Department Name:
Savannah Fire Department
Department City / State:
Savannah, GA
Truck Type:
Dealer – Williams Fire Apparatus
WHEELBASE: 196 ½”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 33’ – ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, 2 ½” Plumbing, (1) 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel
- 1000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- AMDOR Roll-Up Compartment Doors
- Nearly 260 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: S9 – Alum 43/53 Lad Thru Tank, 27” H ID A1
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera (Wired)
- Roto-Ray Warning Light
- FireTech 12V LED Brow
- Federal Signal LED Lightbar
- Federal Signal Rear Beacons
- Federal Signal Quad Taillights
