More Recent Deliveries

Department Name:
Orlando Fire Department
Department City / State:
Orlando, FL



Sutphen Corporation

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 32’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Seven-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left; (2) 3” Right; (1) 2 ½” Left Rear; (1) 2 ½” Right Rear; (1) 1 ½” Front Bumper; (1) 3” Deck Gun
  • Crosslays: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank
  • 30-Gallon Foam
  • Elkhart Foam Supply System with Flush

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Door
  • 222 cu. ft. of Total Compartment Space
  • Alco-Lite PEL-24 (24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute

OPTIONAL EQUIPMENT:

  • 24” Bumper Extension
  • Federal Q2B Siren
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom IV LED Lightbar
  • FRC Spectra 12V LED Brow
  • Whelen PFP2 12V LED Scene
