Delivery Date:
10/19/2022
Department Name:
Nobleboro Fire Department
Department City / State:
Nobleboro, ME

Sutphen Corporation – HS #7113

Dealer – Dingee Machine

WHEELBASE: 215”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 34′ – 4”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 19,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 270 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Left of Main Hosebed, (1) 2 ½” Front Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 2” w/ 1 ½” Swivel
  • 1,000 -Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • AMDOR Roll-Up Compartment Doors
  • 217 cu. ft. Total Compartment Space
  • Alco Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: G2 – Alum 40/51 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Two Camera
  • Hannay Electric Cord Reel, 150’ (1)
  • Generator: 8KW Smart Power
  • Whelen PFH2 LED Brow Light
  • Whelen Freedom LED Lightbar
  • Whelen M9V2 RED/Scene Light
  • Whelen PFH2 12V Telescopic Lights
  • Whelen LED Traffic Advisor
