Delivery Date:
02/15/2019
Department Name:
Nahant Fire Department
Department City / State:
Nahant, MA

WHEEL BASE: 198”

TRAVEL LENGTH: 30’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe Left Rear, (1) 3” Deck Gun
  • 750-Gallon Water Tank
  • Monitor: Akron 3433 Apollo High Rise
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Doors
  • 184 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24 (24’ 2-Section & PRL-14; 14’ Roof & 10’ Folding)
  • Ladder Chute

OPTIONAL EQUIPMENT:

  • 10KW Smart Power Generator
  • Hannay Electric Cord Reel, 175’ (2)
  • Voyager 3, Camera System
  • FRC Spectra Telelight
  • Whelen FN72QLED Lightbar
  • Federal Q2B
  • Whelen M9 Scene Light
  • Whelen PFP2 Brow Light
