Department Name:
Melbourne Fire Department
Department City / State:
Melbourne, FL

WHEEL BASE: 226”

TRAVEL HEIGHT: 9’-8”

TRAVEL LENGTH: 34’-8”

CHASSIS:              Sutphen 73” extended cab with half 10” raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins ISL 9, 400 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 3” Deck Gun
  • 750-Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • Rom Roll-Up Doors
  • Alco-Lite PEL-24
  • 222 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Ladder Chute w/ Backboard Storage
  • Warning Lights, Whelen
  • David Intercom
  • Shoreline Power in EMS Compartment
  • Federal Q2B
  • 18” Bumper
