Delivery Date:
09/12/2017
Department Name:
Canastota Fire Department
Department City / State:
Canastota, NY
Truck Type:

WHEEL BASE: 232”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 41’-5 ¼”

CHASSIS:              Sutphen 73” Extended cab with half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins ISX 12, 500 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX-2000 GPM
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right Rear, 2 ½” Upper Left, (1) 1 ½” Front Bumper, (1) 2 ½” Rear
  • 30-Gallon Foam Tank
  • FoamPro 2002, 5.0 GPM
  • 500-Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • Duo-Safety Ladders
  • Rom Roll-Up Compartment Doors
  • 75 cu. ft. Total Compartment Space
  • Left High/ Right Intermed

OPTIONAL EQUIPMENT:

  • 10KW Harrison Generator
  • Hannay Electric Cord Reel, 150’
  • Little Giant 22’ Defender Ladder
  • Traffic Advisor, Whelen
  • Intercom System, FRC ACT 2-Station
  • Camera System, Intec, Single Camera
  • 18” Bumper
  • Federal Q2B
  • Monitor: TFT Y4-E11A-P-01 Monsoon Elec. w/ M-ERP-1500 Nozzle
