Delivery Date:
09/24/2020
Department Name:
Madison Township Fire Department
Department City / State:
Wyatt, IN

Sutphen Corporation – HS #6675

Dealer – Herb Fire Equipment

WHEELBASE: 226”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 35’ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 400 HP
  • Alternator: Leece Neville, 270 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 2 w/ 1 ½” Swivel
  • Monitor: Elkhart 8297 Stinger w/ 8298 Mount
  • 1,000-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foam System: Hale Smartfoam 2.1A

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • 294 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute
  • Body: G9-Alum 40/51 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Generator: Smart Power 8KW TM HYD
  • Hannay Electric Cord Reel, 150’ (2)
  • FRC Spectra Brow Light
  • Whelen Freedom LED Lightbar
  • Whelen M9V Red Lights
  • Whelen LED Traffic Advisor
  • Command Light KL 415A-FS Command Light Tower
