Delivery Date:
05/23/2022
Department Name:
Lincoln Fire Department
Department City / State:
Lincoln, AL

Sutphen Corporation – HS #7091

Dealer – Williams Fire Apparatus

WHEELBASE: 196 – 0 ½”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33’ – 0 ½”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                   Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-up Compartment Doors, Painted
  • Over 300 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: Pel-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: S9 – Aluminum 43/53 Ladder Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel, Painted
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Backeye 360, Wired
  • Whelen Freedom 81” Fully-Populated Lightbar
  • Whelen M6 Amber LED
  • FR Spectra 12V LED Brow
  • Whelen M9 12V LED Scene
